Product

Model A100 NEW

○ High-end sound that maximizes the Dynamic Range (96dB) characteristics of the phono amplifier.

○ Phono filter circuit design combining CR type and NFB type

○ Provides 4 different EQ curves including a perfect RIAA curve
Curve : 0㎲, 25㎲, 50㎲, 75㎲(RIAA)

○ UTS (Upper Tube Set) method blocks harmonic noise from vacuum tubes

○ Interior design reminiscent of a high-end sports car engine room

○ Adoption of power separation structure and complete channel separation power method

○ THD (0.2%) and excellent SNR (92dB) that overcome the limitations of vacuum tube phono amplifiers

○ Use of special MC boosting transformer

○ 3 colors available: high-glass oak wood, matte oak wood, light wood

Specification

○ Model Name : A100

○ Circuit Type : Tube Phono EQ Amplifier

○ Number of Channels : 2

○ Used Tubes : 12AU7 * 2, 12AX7 * 2

○ Curve : 0㎲, 25㎲, 50㎲, 75㎲(RIAA)

○ Input Sensitivity : 5.5mVrms

○ T.H.D : 0.2%
○ SNR : 92dB

○ Frequency Response : 20Hz ~ 20kHz

○ Impedance : 10 ohm ~ 500 ohm

○ MC Setup : 26dB (1:20)

○ Power Consumption : 35 W

○ Input : 3 × RCA

○ Output : 1 x XLR (BALANCED), 1 x RCA (UNBALANCED)

○ Main AC Power in : 220VAC (210~230VAC available)

○ Size (W x H x D)mm : Main 460 * 130 * 325, Power 460 * 130 * 325

○ Weight : Main 13.9kg, Power 18.3kg
